No. Description Application Keihin No.
Order
No.
34. O-Ring, Pilot Screw All 16075-KG8-9010-M1 021-043
35. Washer, Pilot Screw All 0301-803-2000 021-045
36. Valve Seat (will not work on some OEM)
3.20 All N361-043-3.20 021-240
3.40 All N361-043-3.40 021-241
3.60 All N361-043-3.60 021-242
3.80 All (Std) N361-043-3.80 021-243
4.00 All N361-043-4.00 021-244
37. O-Ring, Valve Seat All 16958-397-7710-M1 021-047
38. Screw, Valve Seat All 0118-806-1100 021-250
39. Float All 1052-856-2100 018-202
40. Arm Pin All W9525-25250 018-670
42. Float Valve All 1062-814-2101 018-504
43. Clip, Float Valve All 0405-019-1000 018-674
44. Fuel Screen All 2009-811-2100 021-730
45. Packing, Float Bowl All 1202-896-6000 021-731
46. Drain Screw All 1198-810-2002 021-733
47. Cover, Accel. Pump All 1230-826-2002 021-057
49. Float Bowl All 1050-948-2101 021-734
49a. Float Bowl w/leak jet Boss All 1050-948-2101 021-734A
51. Diaphragm All 1201-858-2700 021-735
52. U-Ring, Accel. Pump All W9353-36000 021-067
53. Spring, Accel. Pump All 1300-142-2000 021-069
54. O-Ring, Accel. Pump All 16178-548-0040 021-071
55. Cold Starter Valve All 1166-844-2100 021-737
64. Link Lever All 1100-914-2100 021-739
65. Link Lever All 1100-915-7000 021-740
66. Coil Spring #1 All 1305-B01-2001 021-719
67. Coil Spring #2 All 1305-A82-2000 021-717
69. Washer All W1795-223-9900 021-741
70. E-Clip All 16179-676-3000 021-742
72. Rod All 1458-858-2001 021-743
83. Fuel Joint All 1074-892-2100 021-744
85. O-Ring, Fuel Joint All W9351-13057 018-755
90. Idle Speed Screw All 1034-815-4500 021-745
91. Washer All 0301-078-1200 021-101
92. Spring All 1300-112-2000 021-103
96. Throttle Position Sensor (TPS) 1614-862-2100 021-746
100. Screw M4 x 8mm All 0136-804-1100 021-105
103. Main Air Jet All 99101-393-xxx Pg.150
109. Collar All 16145-MZ2-7800 021-747
122. O-Ring All 16173-001-0040 018-664
123. Drain Bolt All 16162-ND4-7511-M1 018-128
140. Screw All 0110-804-1200 021-749
148. Vent Hose All 0803-884-0100 021-751
152. Hose Clip All W9535-3500 018-098
177. Stop Screw All 1034-905-2000 021-722
180. O-Ring All 16978-ZB9-0050 021-732
199. Washer All 0301-261-36G5 021-753
205. Hose Retainer All 16179-KZ4-6900 018-505
206. Vent Hose All 0803-878-0000 021-750
207. Vent Hose All 95003-07033-31 021-752
209. Buffer Plate All 1157-812-7000 021-754
211. Diaphragm All W1470-MW0-7500 021-736
212. Cover All 1230-850-2000 021-755
213. Spring All 1290-A19-2000 021-715
241. Screw (Torx) All 0137-261-36G5 021-757
243. Spring All 1290-A65-2000 021-716
244. Collar All 1118-B36-2000 021-748
245. Hot Start Valve All 1166-845-2100 021-738
249. Washer All W1795-164-9900 021-758
250. Stop Screw All 16124-KR3-6010-M1 021-724
251. Coil Spring All 16053-KT7-0030 021-720
264. Cover All 1230-869-7001 021-756
265. Cover Screw All 0136-839-1100 021-759
FCR-MX Replacement Parts
Applications: FCR-MX37, FCR-MX39, FCR-MX41.
Sudco OEM FCR-MX Float Bowl O-Ring
Genuine KEIHIN replacement part. Sold each. Made in Japan
Order No. 021-731
Application Year
CRF250R 04-09
CRF250X 04-09
CRF250X 2012
CRF450R 02-08
CRF450X 05-09
CRF450X 2012
KX250N1/N2 (KX250F) 04-05
KX250T6F/T7F/T8F/W9F/XAFB (KX250F) 06-10
KLX450A8F/A9F 08-09
KX450D6F/D7F/D8F (KX450F) 06-08
Kawasaki
Honda
Suzuki
Yamaha
KTM
250 SX-F 05-10
250 SXS 2004
250 XC-F Cross Country 07-09
250 XC-W Enduro 06-09
250 XC-W Champions Edition 2010
250 XC-W Six Days 2011
400 EXC-G Racing 04-06
400 EC-W 07-09
450 EXC 10-11
450 EXC-G Racing 04-06
450 EXC-R 2008
450 SMR Supermoto 06-09
450 SX (RFS) 04-06
450 SX-F 07-12
450 XC Cross Country 06-07
450 XC-F 08-09
450 XC-W 09-11
RM-Z250K4-L0 04-10
RM-Z450K5/K6/K7 05-07
WR250FN-FY 02-09
WR250FA/FB 11-12
YZ250FN-FDL/FDW (YZ250F) 02-13
WR400FM 2000
WR426FN/FP 01-02
YZ426FM/FN/FP (YZ426F) 00-02
WR450FR/FS/FT/FV/FW/FX/FY 03-11
YZ450FR/FS/FT/FV/FW/FX (YZ450F) 03-08
YZ450FXL/FXW/FYL/FYW (YZ450F) 08-09
YZ450FSPV 50Th Anniversary 2006
FCR-MX Parts
