Sudco Vol 38

235 / 612

Genuine carburetor screws in different sizes.
Use for float bowl, top cover. Sold each.
Made in Japan.
CW2 = with lock washer C2 = screw only
Two boxes available, 36 compartment and 18 compartment.
Use for valve shim storage, small parts, electrical connectors and
carburetor jets. Sold each.
Description Order No.
Jet Box with 36 Compartments 7-1/2” L x 10-1/2” L x 1-1/4” H 008-001
Jet Box with 18 Compartments 3-1/4” L x 6-3/4” L x 1-1/2” H 008-002
008-001 008-002
Genuine OEM MIKUNI carburetor o-rings. Made in Japan.
Order No. 007-945
Sudco Mikuni Carburetor Dealer O-Ring Kit
Kit includes qt 5 each part number listed below.
(Total qt 75 o-rings and plastic storage box)
O-Ring Description
Size Inside (mm) Mikuni Order
Inside x Thickness Reference No.
3.55 I.D. x 1.78mm BV32/04 002-212
Drain Plug 19.50 I.D. x 1.52mm VM/28/254 002-531
17.50 I.D. x 1.52mm BNO42/64 002-602
8.70 I.D. x 1.95mm BV30/40 002-617
Starter Plunger 8.50 I.D. x 1.55mm VM18/249 002-672
Pilot Air Screw 2.50 I.D. x 1.55mm VM14/75 002-676
Fuel Joint & Needle Vlv. 7.5 I.D. x 1.53mm KV/10 002-709
19.60 I.D. x 2..43mm VM26/227 002-825
Needle Valve 6.70 I.D. x 1.35mm VM24/559 002-838
Pilot Air Screw 2.70 I.D. x 1.13mm N133.037 002-858
Starter/Choke 10.25 I.D. x 1.35mm N138.198 007-160
1.80 I.D. x 1.15mm N124.063 007-163
Fuel Joint 6.25 I.D. x 1.83mm 616-23002 007-182
3.05 I.D. x 1.35mm B30/205 007-188
Needle Valve 8.47 I.D. x 1.53mm 616-33003 007-470
Genuine OEM KEIHIN carburetor o-rings. Made in Japan.
Order No. 018-905
Sudco Keihin Carburetor Dealer O-Ring Kit.
Kit includes qt 5 of each part number listed below.
(Total qt 65 o-rings and plastic storage box)
O-Ring Description Size (mm) Keihin Order
Inside x Thickness Reference No.
18.50 I.D. x 2.85mm 16173-001-0040 018-664
7.90 I.D. x 1.40mm 16075-MB0-0030 018-694
2.65 I.D. x 1.90mm 0901-006-6000 018-722
Fuel T-Joint 5.65 I.D. x 1.33mm W9351-13057 018-755
Pilot Screw 2.70 I.D. x 1.20mm 16075-KG8-9010 021-043
M1 Needle Seat 9.10 I.D. x 1.30mm 16958-397-7710 021-047
U-Ring. 3.55 I.D. x 1.95mm W9353-36000 021-067
Accelerator Pump 4.0 I.D. x 1.05mm W9353-11042 021-070
5.80 I.D. x 1.90mm 16178-548-0040 021-071
U-Ring. 6.35 I.D. x 2.95mm W9353-6500 021-097
Drain Bolt 15.15 I.D. x 1.95mm 16075-935-0060 021-109
Choke O-Ring 8.95 I.D. x 1.35mm 0901-069-6000 021-527
11.75 I.D. x 1.94mm 16978-ZB9-0050 021-732
Application Size Mfg. Order
No. No
Cable Holder Screw 2.6 x 8mm CW2=2608 007-265
Needle Valve Holder Screw 3 x 6.5mm VM13/216 007-174
3 x 8mm CW2=0308 002-479
Throttle Valve Screw 3 x 10mm CW2=0310 002-752
Top Cover Screw 4 x 8mm CW2=0408 007-175
Top Cover Screw TM33 4 x 10mm CW2=410 007-626
Top Cover Screw HSR42 4 x 10mm C5-0410B 007-624
Torx Screw 4 x 12mm VM38/133 002-749
Float Bowl Screw 4 x 12mm CW2=0412 002-748
Float Bowl Screw 4 x 12mm C2=0412-B 007-201
Float Bowl Screw 4 x 14mm CW2=0414 002-522
Float Bowl Screw short TM33 4 x 14mm C2=0414 007-621
Float Bowl Screw long TM33 4 x 16mm C2=0416 007-622
Float Bowl Screw 4 x 16mm CW2=0416 002-823
Float Bowl Screw 4 x 16mm CW2=0416-B 002-615
Float Bowl Screw 5 x 14mm C2=0514-B 007-698
Float Bowl Screw 5 x 14mm CW2=0514 002-516
Float Bowl Screw 5 x 16mm CW2=0516 002-373
Float Bowl Screw 5 x 18mm CW2=0518 002-719
Sudco Keihin Carburetor O-Rings
Sudco Carburetor Screws
Sudco Mikuni Carburetor O-Rings
Sudco Plastic Jet Boxes (Storage Boxes)
