Sudco Vol 38

271 / 612

009-310 009-334 009-331
Description Pingel No. Order No.
1/4” NPT
34mm bolt center A1601C 009-369
3/8” NPT
34mm bolt center A1602C 009-350
44mm bolt centers A1702C 009-352
44mm with offset center hole A1702C-O 009-353
46mm bolt centers A1802C 009-355
50mm bolt centers A1902C 009-357
Blank, drill your own A1902C-B 009-359
Fuel Valve Adapter Plates
2 bolt tank pattern adapter plates to NPT. The adapter plate is bolted
to the tank with the fuel valve threaded into or onto the plate. Adapter
plates come complete with gasket, screws, copper sealing
washers and hylomar sealer.
009-350
009-324
Pingel Power-Flo™ Fuel Valves
People who demand performance demand Pingel® Products. Pingel Fuel Valves provide more fuel flow than OEM petcocks. THIS IS A MUST WITH
drag racing and high performance applications. Manufactured from billet with high quality stainless steel components. Power-Flo™ fuel valves fea-
ture highly polished aluminum or highly polished chrome-plated brass finishes with either 1/4”NPT, 3/8”NPT or HD metric thread 22mm. 5/16” outlet
in single, dual or triple with or without reserve. Fuel Valves listed sold each.
Chrome Plated Adapter Nuts
The adapter nut is threaded onto the tank with the fuel valve threaded
into the nut. Adapter comes with nylon gasket. Sold each.
Description Pingel No. Order No.
Adapts 13/16” or 20mm diameter threaded A2000C 009-370
male tank bung to 1/4” NPT valves
Adapts 7/8” or 22mm diameter threaded A2001C 009-365
male tank bung to 3/8” NPT valves
Adapts 15/16” or 24mm diameter threaded A2002C 009-366
male tank bung to 3/8” NPT valves
Adapts 11/16” or 18mm diameter threaded A2003C 009-371
male tank bung to 1/4” NPT valves
Adapts 22mm diameter threaded A3001C 009-368
male tank bung to 22mm NPT valves
Fuel Valve Reserve Inlet Outlet Order
Pingel No. 5/16” No.
1211-AH (Hex) Yes 3/8” NPT Single 009-303
1211-CH6 Yes 3/8” NPT Single 009-320
1311-AH (Hex) Yes 22mm Metric Single 009-300
1311-CH Yes 22mm Metric Single 009-328
3110-D-AH No 1/4” NPT Dual 009-309
3110-D-AH16A No 1/4” NPT Dual 009-331
3210-D-AH No 3/8” NPT Dual 009-310
3211-D-AH Yes 3/8” NPT Dual 009-311
32GSXR No 3/8” NPT Dual 009-312
3311-D-AH Yes 22mm Metric Dual 009-334
4110-AH61A No 1/4” NPT Single 009-338
4111-CH3 Yes 1/4” NPT Single 009-322
Fuel Valve Reserve Inlet Outlet Order
Pingel No. 5/16” No.
4211-AH Yes 3/8” NPT Single 009-304
4211-CH6 Yes 3/8” NPT Single 009-323
4311-AH Yes 22mm Metric Single 009-301
4321-CH Yes 22mm Metric Single 009-324
6111-AH Yes 1/4” NPT Single 009-307
6210-AH No 3/8” NPT Single 009-314
6211-AH Yes 3/8” NPT Single 009-305
6211-CH Yes 3/8” NPT Single 009-336
6211-CR Yes 3/8” NPT Single 009-337
6311-AH Yes 22mm Metric Single 009-302
6381-CH Yes 22mm Metric Single 009-327
8210-T-AH No 3/8” NPT Triple 009-316
Honda
Model Year Fuel Valve Reserve Number of Size of Order Description/Notes Adapter Order
Pingel No. Outlets Outlets No. Pingel No. No.
CB550 6111-AH Yes Single 5/16” /straight 009-307 Adapter nut required A2000C 009-370
CBR600F2/F3 Hurricane 91-98 3311-D-AH Yes Dual 5/16” /straight 009-334 Adapter included –––––– ––––––
CBR600F4 Hurricane 3311-D-AH Yes Dual 5/16” /straight 009-334 Adapter included A2003C 009-370
CB750F Super Sport 6111-AH Yes Single 5/16” /straight 009-307 Adapter nut required –––––– ––––––
VF750C Magna 4321-CH Yes Single 3/8” /straight 009-324 Adapter included –––––– ––––––
VF750S Sabre 6111-AH Yes Single 5/16” /straight 009-307 Adapter nut required A2000C 009-370
Fuel Valves V
intage
i
ntake
e
ngine
s
uspension
c
ontrol
e
lectrical
c
hemical
t
ools
W
atercraft
263
