Sudco Vol 38

363 / 612

Application Use Street APE Spring. Spring Order. APE Retainer Retainer
Order No No No. No.
Honda 750 SOHC thru ‘78 street/race (TQ Midgets) stock VS750H 875-330 TVSRH750 (Kmodel) 875-390
Kawasaki ZX7 ‘91-’95 kit type Race ––––––– ––––––– TVSRK750 875-370
Kawasaki ZX7 ‘96-’99 VS750K 875-300 TVSRK750-96 875-371
Kawasaki ZX9 ‘98-’00 ––––––– ––––––– TVSRK750-96 875-371
Kawasaki 650 thru 1100 2 valve up to .460” lift stock VS900K 875-301 TVSRK1000 (sob) 875-372
Kawasaki 900 thru 1100 2 valve .460” .510” lift VSP500 875-302 TVSRK1000 (sob) 875-372
Kawasaki/Suzuki 2 Valve race up to .540” lift VSP520 875-303 TVSRK1000 (sob) 875-372
Kawasaki Ninja 900/1000 includes bases stock VS908KS 875-305 ––––––– –––––––
Kawasaki ZX10/ZX11 includes bases stock VS1100K 875-306 TVSRK1100 875-374
Kawasaki ZX12 65 lbs seat pressure VS1200K 875-307 ––––––– –––––––
Suzuki GS1100/1150 street/race stock VS1100S 875-320 TVSRS1100 875-378
Suzuki GS1100/1150 pro race 60# @ 1.250”, .460” lift VS1100S-PRO 875-321 TVSRS750 875-379
Suzuki GSXR750 86-90 street/race stock VS750GSX 875-322 TVSRS750 875-379
Suzuki GSXR750 ‘91-’92 (shim style) street/race ––––––– ––––––– TVSRS750SH 875-380
VSA204 shims req’d
Suzuki GSXR750W ‘93-’95 street/race ––––––– ––––––– TVSR1100SX 875-381
Suzuki GSXR750T ‘96-’99 street/race ––––––– ––––––– TVSRS750-96 875-382
Suzuki GSXR1100 ‘93-’99 street/race stock ––––––– ––––––– TVSR1100GSX 875-383
Suzuki GSXR1300 Hayabusa w/ stock springs ––––––– ––––––– TVSR1300GSX 875-384
Suzuki GSXR1300 Hayabusa race w/ APE springs VS1300GSX 875-325 TVSR1300PRO 875-385
45 lbs of seat pressure with a .015”shim
Suzuki GS550 thru 1000 2 valves street/race stock VS1100S 875-320 TVSRK1000 (sob) 875-373
High seat pressure (65lbs) for high lift cams or high boost turbo VS1300GSX-2 875-327
Yamaha FJ1100/1200 street/race/legends stock VS1100FJ 875-341 TVSR1100Y (sob) 875-397
Triumph Daytona 4-cylinder street/race stock VS1200T 875-350 ––––––– –––––––
APE High Performance Valve Springs
APE valve guides are made from special bronze alloy to resist wear
and heat. Precision machined with the bores finished to size. They are
designed to fit lower in the cylinder head to clear high lift cams, and use
APE seals or factory OEM seals. Sold in sets for models listed.
APE Titanium Valve Spring Retainers
APE valve spring retainers are machined from aircraft quality titanium
bar stock in the APE plant on the latest state of the art computerized
CNC machinery. Sold in sets for models listed.
Motion Pro Valve Spring Compressor
Improved quick action design, used in same applications as
Honda tool 07757-0010000 and Kowa tool AKS-215-1010 OEM
tools. Accepts Motion Pro adapters (08-0248) as well as Honda OEM
adapters 07GME-KT70200, 07JME-KY20100, and 07959-KM30101.
For use in shim under bucket and small diameter valve spring keeper
applications, both cup-type and ball-type tips are included. Adapter on
compressor is double stepped. The inner step diameter is
17mm - Outer step diameter is 21mm.
Order No. 950-772
APE Performance Products
355
