No. Description Application Keihin No. Order No.
51. Diaphragm All 1201-858-2400 021-065
52. U-Ring, Accel. Pump All W9353-36000 021-067
53. Spring, Accel. Pump All 1300-142-2000 021-069
54. O-Ring, Accel. Pump All 16178-548-0040 021-071
64. Link Lever 28-33mm 1100-868-2100 021-073
35-41mm 1100-870-2100 021-074
65. Link Lever Downdraft 1100-867-7001 021-076
Horizontal 1100-872-7000 021-252
66. Coil Spring #1 All 1305-933-2000 021-078
67. Coil Spring #2
Downdraft 28-33mm 1305-934-2000 021-080
Downdraft 35-41mm 1305-939-2000 021-081
Horizontal All 1305-952-2000 021-254
68. Rod, Link Lever All 1458-825-2000 021-083
Rod, Link Lever GSX-R 1458-827-2000 021-256
(liquid cooled)
Flat, Link Arm 1061-818-2100 021-022
69. Washer, Rod Link All 0301-136-7000 021-085
70. Pin, Link Lever All W9251-12081 021-087
71. Rubber Cap All 1028-825-2001 021-089
72. Rod Downdraft 1458-826-2000 021-091
Horizontal 1458-829-2000 021-255
73. Washer, Link Lever All 0301-114-1100 021-093
74. Collar, Link Lever All W1704-241-9900 021-095
76. Bolt M5
M5 x 95mm CBR600 0136-801-1100 021-145
M5 x 95mm FZR400/600 0136-801-1100 021-145
M5 x 100mm ZX-6, ZX-7 0136-811-1100 021-147
M5 x 100mm ZX-10, ZX-11 0136-811-1100 021-147
M5 x 110mm FZR750/1000 0136-812-1100 021-149
M5 x 90mm (*Option) 0136-809-1100 021-146
77. Spacing Collar #1
56mm CB-1, CBR600N704-01056 021-153
56mm FZR400/600 N704-01056 021-153
60mm ZX-6, N704-01060 021-155
60mm ZX-10, ZX-11 N704-01060 021-155
71mm FZR750/1000 N704-01071 021-157
50mm (*Option) N704-01050 021-151
53mm (*Option) N704-01053 021-152
68mm (*Option) N704-01068 021-156
78. Spacing Collar #2
71mm ZX-7, N704-02071 021-161
71mm ZX-10, ZX-11 N704-02071 021-161
77mm CB-1, N704-02077 021-163
77mm FZR750/1000 N704-02077 021-163
81mm ZX-6, CBR600 N704-02081 021-167
81mm FZR400/600 N704-02081 021-167
50mm (*Option) N704-02050 021-158
53mm (*Option) N704-02053 021-159
68mm (*Option) N704-02068 021-160
89mm (*Option) N704-02089 021-168
79. Spacing Collar #3
71mm ZX-10, ZX-11 N704-03071 021-171
77mm CB-1 N704-03077 021-173
77mm FZR750/1000 N704-03077 021-173
81mm CBR600, ZX-6 N704-03081 021-175
81mm FZR400/600 N704-03081 021-175
56mm (*Option) N704-03056 021-169
60mm (*Option) N704-03060 021-170
65mm (*Option) N704-03065 021-172
68mm (*Option) N704-03068 021-174
89mm (*Option) N704-03089 021-176
80. Rubber Pipe
34mm CBR600 0804-985-0000 021-179
34mm FZR400/600 0804-985-0000 021-179
34mm CB-1, ZX-7 0804-985-0000 021-179
34mm ZX-10, ZX-11 0804-985-0000 021-179
41mm ZX-6 0804-990-0000 021-181
46mm FZR750/1000 0804-992-0000 021-183
31mm (*Option) 0804-988-0000 021-180
No. Description Application Keihin No. Order No.
81. Air Vent Joint 4-cylinder 1077-826-7000 021-187
(Breather) Ducati (Dual) 1077-806-7001 021-188
82. U-Ring, Air Vent All W9353-65000 021-097
84. Fuel Joint (center) CBR600, CB-11075-834-2000 021-191
FZR400/600 1075-834-2000 021-191
FZR750/1000 1075-834-2000 021-191
ZX-7 1075-836-2000 021-193
ZX-10, ZX-11 1075-836-2000 021-193
85. O-Ring, Fuel T-Joint All(Ex Ducati) W9351-13057 018-755
Ducati Duals Only Duals 16178-548-0040 021-071
88. Rubber Pipe
45mm (R & L side.) CBR600, CB-1W1785-032-9900 021-197
45mm (R & L side.) FZR400/600 W1785-032-9900 021-197
60mm (R,L & C) FZR750/1000 0804-437-0001 021-201
60mm (R,L & C) GSX-R750 93-95 021-201
70mm ZX-7 0804-986-0000 021-209
70mm ZX-10, ZX-11 0804-986-0000 021-209
40mm (*Option) 0804-444-0000 021-202
50mm (*Option) 0804-991-0000 021-203
80mm (*Option) 0804-987-0000 021-210
89. Fuel T-Joint
CBR600, CB-11077-804-7000 018-751
FZR400/600 1077-804-7000 018-751
ZX-6 1077-804-7000 018-751
ZX-10, ZX-11 1077-804-7000 018-751
FZR750/1000 1077-803-7000 018-753
GSX-R 1077-803-7000 018-753
(liquid cooled)
Downdraft 1074-848-2100 021-251
(single)
Ducati (Dual) 1077-844-2000 021-190
90. Idle Speed Screw All 1034-837-2100 021-099
13.25” 1034-837-2501 021-531
91. Washer All 0301-078-1200 021-101
92. Spring All 1300-112-2000 021-103
100. Screw, Bracket All 0136-804-1100 021-105
103. Main Air Jet 35-41mm 99101-393-XXX Pg.150
121. Float Bowl #2 Downdraft 1050-863-2100 021-107
with right pull
Float Bowl #3 Downdraft 1050-863-2100 021-107
with center pull
Float Bowl #2 Horizontal 1050-882-2100 021-261
with right pull
Float Bowl #3 Horizontal 1050-882-2100 021-261
with center pull
122. O-Ring, Drain Bolt All 16075-935-0060 021-109
123. Drain Bolt All 1018-804-2000 021-111
124. Rubber Pipe
60mm length ZX-6, ZX-7 0804-437-0001 021-201
60mm length ZX-10, ZX-11 0804-437-0001 021-201
70mm length CBR600, CB-10804-986-0000 021-209
70mm length FZR750/1000 0804-986-0000 021-209
80mm length (*Option) 0804-987-0000 021-210
125. Mounting Adapters (Spigots) Pg.110-111
126. Velocity Stacks - Sold each
Blue, 50mm long 28-33mm 1130-806-7002 021-113
Blue, 50mm long 35-41mm 1130-807-7000 021-114
Red, 30mm long 35-41mm 1130-808-7000 021-115
127. Rubber Cap, T-Joint All 1028-808-7000 018-759
128. Clip, Rubber Cap All W9535-55000 018-761
129. Air Filter Adapters Pg.120-121
130. O-Ring, Air Cleaner 35-41mm 021-439
Adapter
See page 109 for FCR Carburetor Rebuild Kits. See Pages
110-113 for additional FCR parts and accessories
FCR Parts
