132

ORDER: 800-998-3529

TECH: 310-637-8330

Non Air Striker PWK33, 35, 36, 38, 39, 41

PWK 35, 38 Air Striker/Quad Vent

Carburetor

Main

Slow Jet

Throttle Valve

Float

Description/Mark

Order No.

Jet

Jet

Needle

Cutaway

Height

PWK28

#135 #38

46-JJH

3.5

19mm

PWK28/29S

016-144

PWK33

#165 #52

48-CGL

6.0

16mm

PWK33/S46

016-148

PWK35

#160 #68

48-DGK

6.0

16mm

PWK35/70R

016-150

PWK38

#172 #58

48-DEG

6.0

16mm

PWK38/71R

016-153

PWK39

#160 #60

48-DGH

6.0

16mm

PWK39/72R

016-155

PWK41 Pro-Series

#160 #60

48-DGH

6.0

16mm

PWK41 Pro-Series

016-156

Carburetor

Description/Mark Special Set

Order No.

PWK28 Non Air Striker

PWK28/29S

016-189

PWK33 Non Air Striker

PWK33/S46

016-191

PWK35 Non Air Striker

PWK35/70R

016-192

PWK35 Quad Vent/Air Striker

PWK35 A.S./S65

016-197

PWK36 Quad Vent

PWK36/S63

016-198

PWK38 Non Air Striker

PWK38/71R

016-194

PWK38 Quad Vent/Air Striker

PWK38 A.S./S66

016-199

PWK39 Non Air Striker

PWK39/72R

016-195

PWK36 Quad Vent

Includes parts

A thru F.

listed below. All PWK carburetors.

Order No.

018-501

A.

Cable Sealing Cap

16118-166-0040

018-002

B.

Choke Plunger

W1275-028-9901

021-512

C.

Choke O-Ring

0901-069-6000

021-527

D.

Spring

1290-922-2000

021-582

E.

Cable Holder

W1551-140-9900

021-583

Keihin PWK Series Carburetors

Producing power without compromise, Keihin PWK carburetors have set the standard for ATV, motocross, and offroad racing

carburetors. Because of there great performance, they come stock on a lot of leading brand names. PWK features include:

• Chromed semi-flat (D shape) throttle valve for excellent response and more flow at high RPM.

• Throttle Bores sized to give maximum power.

• Quad Vents - Eliminates post jump bogging from fuel plugged vent passages.

• PWK Air Strikers - Directs air to main nozzle for improved signal and throttle response.

PWK carburetors are available in Standard (Non Air Striker) and Air Striker/Quad Vent. Sold each.

PWK (Non Air Striker) Standard Jetting Specifications

PWK Quad Vent/Air Striker Standard Jetting Specifications

PWK35 Quad Vent/Air Striker #160

#48

48-DEK

4.5

16mm

PWK35 A.S./S65

016-160

PWK36 Quad Vent

#165 #55

48-DGJ

5.0

16mm

PWK36/S63

016-163

PWK38 Quad Vent/Air Striker #170

#55

48-DDJ

7.0

16mm

PWK38 A.S./S66

016-167

Note:

* X00 represents product code stamped on the carburetor body just above the float bowl.

Sudco Choke Cable System for all PWK’s

PWK Special Set Carburetors

Use the following part numbers when ordering for special jetting

request.

Please note:

Special Set carburetors are pre-jetted to your

request or specific application. Please specify exact jetting details or

bike application for each special set carburetor ordered.

PWK Carburetors
