Exploded
View No. Qt Contents
5. 1 Gasket, Float Bowl
7. 1 O-Ring, Plug Screw
8. 1 Float Valve Complete
12. 1 Clip, Jet Needle
16. 1 Gasket, Top
17. 1 Air Adjust Screw
18. 1 Spring, Air Adjust Screw
20. 1 Clip, Float Valve
21. 2 Screw, Float Bowl
24. 1 Float Pin
29. 1 Idle Adjuster (for Chrome T/V)
30. 1 Spring, (for Chrome T/V)
32. 2 Screw, Top Cover
Cutaway Keihin No. Order No.
Rich 1.0 N502-52B00 018-584
2.0 N502-52C00 018-585
3.0 N502-52D00 018-586
3.5 (Std) N502-52H00 018-590
4.0 N502-52E00 018-587
5.0 N502-52F00 018-588
Lean 6.0 N502-52G00 018-589
Sudco PWK 28 Carburetor Rebuild Kit
Sudco rebuild kit for the Keihin PWK28 contains GENUINE Keihin
replacement parts. Sold as a kit.
Order No. 020-112
PWK 28 Throttle Valve Chart
A. Cable Sealing Cap 16118-166-0040 018-002
B. Choke Plunger W1275-028-9901 021-512
C. Choke O-Ring 0901-069-6000 021-527
D. Spring 1290-922-2000 021-582
E. Cable Holder W1551-140-9900 021-583
Sudco Choke Cable System for all PWK’s
Includes parts A thru E listed below. All PWK carburetors.
Order No. 018-501
Tokyomods Drain Plug
Keeps all fuel contaminates including water away from the main jet,
helps control fuel slosh and bogging, won’t get distorted from over
tightening, and easy to reach for quicker jetting changes. Machined
from 6061 aluminum. Also fits Keihin FCR-MX, PJ, PWK, PWM, and
PE carbs.
Application Color Order No.
FCR-MX, PJ, PWK,
PWM, PE
Red 024-230R
Blue 024-230B
Black 024-230K
Mag 024-230M
PWK 28 Parts
