ORDER: 800-998-3529
TECH: 310-637-8330
Mikuni No.
Order No.
RS34-D21
001-319
RS36-D3
001-320
RS36-D8
001-321
RS38-D19
001-325
RS38-D35
001-326
RS40-D1
001-330
RS40-D12
001-331
Designed for in-line four cylinder performance motorcycles, the Mikuni RS Series Radial Flat Slide Carburetors offer superior horsepower
gains with their maximum flowing smoothbore induction tract and radial flat slide design. An adjustable accelerator pump system helps to provide
instant throttle response, particularly in the lower RPM range. The RS Series Carburetors feature a compact design which is 25% lighter than other
performance Carburetors and uses readily available Mikuni jets. Available sizes : RS34, RS36, RS38 and RS40mm.
Features of the RS Series Carburetors
•
Adjustable Pump Adjust Screws. Sets ON and OFF operation of
accelerator pump in relation to throttle slide position.
•
Throttle Return Spring. A choice of positioning pegs allow
adjustment of spring tension.
•
Idle Adjustment Screw. Controls engine idle speed.
•
Adjustment Accelerator Pump. Squirts fuel into carburetor venturi
when throttle is opened to improve engine response.
•
Starter System. Provides fuel enrichment for cold engine starting.
•
Adjustable Pump Spray Nozzle. Shoots fuel directly into the intake
tract for immediate engine response.
Features of the RS Series Carburetors
•
Jet Needle Clip. Easy adjustment feature for quick adjustment.
•
Flat Throttle Valve Design. Provides the strongest signal for
precise and instantaneous throttle response.
•
Float Bowl Vent. Allows atmospheric pressure into float bowl
for fuel flow.
•
Smooth Throttle Bore/Venturi. Produces the optimum air and fuel
mixture flow at all RPM’s.
•
Genuine Mikuni Jets and Tuning Components. Provides for
precise fuel metering.
•
Pilot Air Jet. Use in conjunction with the Pilot Fuel Screw for
tuning of mixture at idle to 1/4 throttle.
Available in 34, 36, 38 and 40mm bore sizes with different carb spacing for particular bike applications and with different jetting to match engine
modifications. Please see application chart listing on next page.
Note:
These are guidelines only. Specifications are subject to change.
IMPORTANT:
Mikuni RS Carburetors are legal in California ONLY FOR RACING VEHICLES WHICH MAY NEVER BE USED
UPON A PUBLIC STREET OR HIGHWAY. In other locations check for similar laws which may apply.
Mikuni RS Smoothbore Carburetors
Ordering RS Smoothbore Carburetors
Mikuni No.
Order No.
RS36-D9
001-322
RS38-D29
001-327
RS40-D7
001-332
Center Bell Crank
Left Side Bell Crank
RS Smoothbore
