Mikuni No. (Part Number) in application chart above
denotes size in millimeters. RS34-D21 = RS34.
• Uses left side throttle linkage.
• Applications (General) - These are guidelines only.
Specifications are subject to change.
• RS34 and RS36 Carburetors may use Jet Needle #9DZH05.
• RS38 and RS40 Carburetors may use Jet Needle #9CHY10.
Pre Kawasaki KZ1000J models require qt 4 mounting flanges.
Order No. 005-866, Qt 4 set.
Carburetor Spacing (mm):
A 20 2 3 4 B C
Standard Jetting Specifications Center Bell Crank
Standard Jetting Specifications Left Bell Crank Uses left side throttle linkage.
RS Series Notes
RS Smoothbore
Mikuni No. Application Carb Spacing Spigot Main Jet Jet Needle Needle Pilot Pilot
* (General) (Throttle Shaft No.) (O.D.) N100.604 (J8-) Jet #568 Jet Screw
A-B-C MM (Clip Pos.) (784-13002) (VM28/486) (Turns)
RS34-D21 Suz GSX600F Katana (1988) 77-93-77 40 115 9DZH01* P-4 17.5 1/4-1/2
Suz GSX-R750 (88-92) (700-17011) 115 (-3)
Suz GS750 115
Kaw KZ750
RS36-D8 Kaw ZX900A Ninja (84-86) 77-85-77 42 130 9DZH01* P-4 17.5 1/4-1/2
Kaw ZX1000A Ninja (86-87) (700-17011) 130 (-3)
Yam FJ1100 (84-85) 130
Yam FJ1200 (86-92) 130
RS36-D3 Kaw KZ1000J/K/M/R (81-83) 77-93-77 42 120 9DZH01* P-4 17.5 1/4-1/2
Kaw KZ1100A/D (81-85) (700-17011) 120 (-3)
Suz GSX600F Katana (1988) 120
Suz GS1000/1100/1150 120
Suz GSX-R750/1100 Air Cooled 120
RS38-D19 Kaw KZ1000J/K/M/R (81-83) 77-93-77 42 135 9CHY03* Y-6 17.5 1/4-1/2
Kaw KZ1100A/D (81-85) (700-17011) 135 (-3)
Suz GSX600F Katana (1988) 135
Suz GS1000/1100/1150 135
Suz GSX-R750/1100 Air Cooled
RS38-D35 Kaw ZX900A Ninja (84-86) 77-85-77 42 130 9CHY03* Y-6 17.5 1/4-1/2
Kaw ZX1000A Ninja (86-87) (700-17011) 130 (-3)
Yam FJ1100 (84-85) 130
Yam FJ1200 (86-92)
RS40-D12 Kaw ZX900A Ninja (84-86) 77-85-77 44 140 9CHY03* Y-6 17.5 1/4-1/2
For Race Kaw ZX1000A Ninja (86-87) (700-17011) 140 (-2)
use Yam FJ1100 (84-85) 140
on models Yam FJ1200 (86-92) 140
listed
RS40-D1 Kaw KZ1000J/K/M/R (81-83) 77-93-77 44 140 9CHY03* Y-6 17.5 1/4-1/2
For Race Kaw KZ1100A/D (81-85) (700-17011) 140 (-3)
use Suz GS1000/1100/1150 140
on models Suz GSX-R750/1100 Air Cooled 140
listed
•• RS36-D9 Kaw KZ1000J/K/M/R (81-83) 77-93-77 42 120 9DZH01* P-4 17.5 1/4-1/2
Kaw KZ1100A/D (81-85) (700-17012) 120 (-3)
Suz GSX600F Katana (1988) 120
Suz GS1000/1100/1150 120
Suz GSX-R750/1100 Air Cooled 120
** RS38-D29Kaw KZ1000J/K/M/R (81-83) 77-93-77 42 135 9CHY03* Y-6 17.5 1/4-1/2
Kaw KZ1100A/D (81-85) (700-17012) 135 (-3)
Suz GS1000/1100/1150 135
Suz GSX-R750/1100 Air Cooled 135
** RS40-D7 Kaw KZ1000J/K/M/R (81-83) 77-93-77 44 140 9CHY03* Y-6 17.5 1/4-1/2
For Race Kaw KZ1100A/D (81-85) (700-17012) 140 (-3)
use Suz GS1000/1100/1150 140
on models Suz GSX-R750/1100 Air Cooled 140
listed
