VM33 Smoothbore Replacement Parts

• Lined through part numbers are no longer available.

No. Description

Mikuni No.

Order No.

1.

Mixing Body

VM33SS101/01B

–––––––

2.

Mixing Body

VM33SS101/01C

–––––––

3.

Mixing Body

VM33SS102/01C

–––––––

4.

Mixing Body

VM33SS103/01B

–––––––

5.

Gasket

VM33/31

002-600

6.

Jet Block

VM33/20

–––––––

7.

O-Ring

BNO42/64

002-602

8.

Drain Plug

TM32/41

007-646

9.

Washer, Needle Valve

B34/52-0.5

002-187

10.

Assembly, Needle Valve

(2.5)

N122.032-2.5

002-503

Assembly, Needle Valve

(2.8)

N122.032-2.8

002-504

11.

Float Pin

VM30/160

002-605

12.

Filter Screen

VM18/233

002-606

13.

E-Ring

VM20/369

002-083

14.

Gasket, Float Bowl

VM30-257

002-607

15.

Jet Needle

J8-6DJ30

002-340

16.

Needle Jet

#261 Series, O-8

003-536

17.

Main Jet Extender

697-05001A

002-608

18.

Main Jet

N100.604

Pg.214

19.

Screw

C6=0307

002-609

20.

Float Assembly

VM26/260

002-501

21.

Float Chamber Body

VM29/20-100

–––––––

22.

Hose, Air Vent

888-36003A

–––––––

23.

Fuel Nipple

792-20008

002-612

24

.

Washer

VM28/268

–––––––

25.

E-Ring

BN38/135

002-614

26.

Screw with Lock Washer

CW2=0416-B

002-615

27.

Fuel Nipple

792-20007

–––––––

28.

O-Ring

BV30/40

002-617

29.

Throttle Valve 1.5

832-39003-1.5

003-198A

Throttle Valve 2.0

832-39003-2.0

003-198

Throttle Valve 2.5

832-39003-2.5

003-198B

30.

Bushing Collar

VM33/60

–––––––

31.

Bracket Assembly

VM33/71

002-619

32.

Screw with Lock Washer

CW2=0305

002-527

33.

Gasket, Top Cover

VM33/32

002-620

34.

Adjuster Nut

N138.050

002-621

35.

Adjuster Screw

VM33/21

–––––––

36.

Screw

730-06005

–––––––

37.

Lever Assembly

VM33/64

002-624

38.

Top Cover

776-39001

002-625

39.

Lock Washer

W4-04-0

002-626

40.

Bracket Plate, Front

VM33/75

002-627

41.

Screw

C2-0512-B

002-628

42.

Washer (Polyester)

B40I/10

002-629

43.

Plate, Connecting

VM33/45

002-630

44.

Spring

VM33/49

002-631

45.

Washer

M10/56

002-632

46.

E-Ring (Clip)

BSW28/70

002-355

47.

Collar Pipe

813-28001

002-633

48.

Shaft

700-17003A

002-634

49.

Lever Assembly

VM33/52A

–––––––

50.

Screw

VM33/73

002-636

51.

Screw

C5=0510

–––––––

* Please Note: The following is for parts reference only. This Mikuni carburetor is no longer in production.

No. Description

Mikuni No.

Order No.

52.

Bolt

VM28/230

002-519

53.

Lever Assembly

VM33/26

002-638

54.

Name Plate

VM33/78

–––––––

55.

Collar

VM33/68A

002-639

56.

Seal, Felt

VM28/403

002-640

57.

Screw with Lock Washer

CW2=0416B

002-615

58.

Hose, Air Vent

N149.030

002-641

59.

Screw

N138.186

002-642

60.

Bracket Plate, Rear

VM33/67

002-643

61.

Bell Crank Assembly

VM33/38

002-644

62.

Spring

VM33/35

002-645

63.

Vacuum Cap

N148.013

002-646

64.

Throttle Return

VM22/349

002-647

65.

Screw

C2-0508-B

002-648

66.

Adjuster Plate

VM33/34

002-649

67.

Bracket

VM33/23

002-650

68.

Choke Shaft Plate

VM33/58

–––––––

69.

Screw

C2-408-B

002-652

70.

Cap, Side

VM33/63

002-653

71.

Pilot Jet

VM22/210

Pg.212

72.

Adjuster Screw

N138.049A

002-654

73.

Spring

N110.209

002-655

74.

Washer

N141.217

–––––––

75.

Main Bracket

VM33/43

–––––––

76.

Adjuster Screw

603-25001A

–––––––

77.

Screw

N158.052

002-659

78.

Lever

VM26/435

002-660

79.

Cap Side

VM33/70

002-661

80.

Fuel Cap

VM33/72

–––––––

81.

Ring

VM24/532

–––––––

82.

Washer

VM28/449

002-664

83.

Spring

VM28/293

002-665

84.

Screw

VM28/269

–––––––

85.

Choke Shaft Assembly

VM33/56A

–––––––

86.

Screw

C2-0306-B

002-668

87.

Side Plate

VM33/59

002-669

88.

Starter Plunger

VM24/510

002-670

89.

Plunger Spring

VM16/42A

002-671

90.

O-Ring

VM18/249

002-672

91.

E-Ring

KP/13

002-673

92.

Ring

VM28/450

–––––––

93.

Rubber Cap

VM20/455

002-084

94.

Guide Holder

VM38/359

–––––––

95.

Spring

M12F/46A

002-181

96.

O-Ring

M14/75

002-676

97.

Air Screw

VM26/287

002-677

98.

O-Ring

0S/05B

–––––––

99.

Lock Washer

W4-05

002-679

100.

Washer

BV23/196

002-680

101.

Bearing

VM33/61

–––––––

102.

Seal, Felt

VM33/37

–––––––

103.

Washer

946-17001

002-683

105.

Air Jet

BS30/97

Pg.213

106.

Restrictor

VM33/82

002-684

Size

Mikuni No.

Order No.

2.5

N122.032-2.5

002-503

2.8

N122.032-2.8

002-504

VM33 Needle Valve Assembly

(No.10 exploded view)

Cutaway

Mikuni No.

Order No.

1.5

832-39003

003-198A

2.0

832-39003

003-198

2.5

832-39003

003-198B

VM33 Throttle Valves

(No.29 exploded view)

VM33 Smoothbore Parts
