For the performance engine builder needing the carburetor only

for specific custom applications. Available in standard aluminum finish

or polished version.

Description

Mikuni No.

Order No.

42mm Carb only, standard finish

TM42-6

001-549

42mm Carb only, polished finish

TM42-6PK

001-551

45mm Carb only, standard finish

TM45-2K

001-554

45mm Carb only, polished finish

TM45-2PK

001-555

48mm Carb only, standard finish

TM48-1

001-558

48mm Carb only, polished finish

TM48-1PK

001-559

Note:

001-549

- use stock choke cable from H-D CVK type carb.

Kits contain all the necessary parts and gaskets to rebuild an HSR

carburetor. Includes needle valve assembly, o-rings, gaskets and screws.

Sold as a kit.

Description

Mikuni No. Order No.

HSR42/45mm Carburetor Rebuild kit

KHS-016

002-989

HSR48mm Carburetor Rebuild kit

KHS-031

002-982

Qt

Contents

1

Gasket, Top Cover

1

E-Ring, Jet Needle

1

Washer, Jet Needle

1

O-Ring, Pilot Air

2

O-Ring, Fuel Joint

1

O-Ring, A/P

1

O-Ring, Needle Valve

1

Screw, N.V. Retainer

1

Needle Valve Assy #4.2 (HSR42/45)

Needle Valve Assy #4.5 (HSR48)

1

Packing, Float Bowl

1

Hose, Overflow

1

O-Ring, Drain Plug

4

Screw, Float Bowl (short)

1

Boot, A/P Rod

Size Description

Mikuni No.

Order No.

(2.3) Fuel Pump

786-27001

007-478

(3.5) Offroad

786-27001

007-477

(4.2) Std on HSR42/45

786-27001

007-476

(4.5) Std on HSR48

786-27002-1A-4.5

007-708

O-ring for Needle Valve Seat

616-33003

007-470

HSR42/45/48 Carburetor Rebuild Kits

HSR Needle Valve Assemblies

Sold each.

HSR42 Dealer Jet Assortment Kit

This jet assortment kit contains 44 pieces in a special jet box. Included

are qt 2 each #150 thru #170 main jets, qt 2 each #20 thru #32.5 pilot

jets, qt1 each #96, #97 and #98 needles, qt2 each #60 a/p nozzles,

needle clips and washers. Sold as a kit.

Description

Mikuni No. Order No.

44 Pc. Jet Kit Assortment with storage box

KHS-025

002-983

Mikuni Individual HSR Carburetors

Description

Mikuni No.

Order No.

Standard

TM42/11-70

007-487

Leaner

TM42/11-60

007-486

Leanest

TM42/11-50

007-485

HSR45 & HSR48 Dealer Jet Assortment Kit

HSR Accelerator Pump Nozzles

Sold each.

HSR Main Jet Extender Kit

Description

Mikuni No.

Order No.

Main Jet Extender Kit

KHS-034

002-978

Description

Mikuni No. Order No.

HSR45 Jet Kit

KHS-045

002-976

HSR48 Jet Kit

KHS-048

002-977

HSR Carburetors, Parts & Accessories

V

intage

i

ntake

e

ngine

s

uspension

c

ontrol

e

lectrical

c

hemical

t

ools

W

atercraft

171
