188
ORDER: 800-998-3529
TECH: 310-637-8330
Carburetor Main
Pilot
Jet
Throttle Valve
Needle
Float
Mikuni
Order
Jet
Jet
Needle Cutaway
Valve Set
Height
No.
No.
TMX35-1 4/042 #350 VM22/210 #20 6EN11-53 9998-832-014-6.0 786-36004-3.5 20mm
TMX35-1
001-034
TMX38-18 4/042 #370 VM22/210 #20 6EJ12-55 9998-832-014-3.5 786-36004-3.5 20mm
TMX38-18
001-076
TMX38-27 4/042 #370 VM22/210 #20 6EJ12-55 9998-832-014-3.5 786-36004-3.5 20mm
TMX38-27
001-077
Mikuni TMX Series Carburetors are intended for off-road
riding and racing use only. Not legal for use in California or
other locations where similar pollution laws may apply.
TMX Flat Slide Carburetors (Early Style) Standard Jetting
Size (mm)
A
B
C
D Total Width
TMX35-1
40
76
164
62 76
TMX38-18
47
76
164
62 76
TMX38-27
44
76
164
62 76
TMS38-77
44
76
164
62 76
TMS38-78
47
76
164
62 76
Note: TMS carburetor is no longer in production.
Carburetor Dimensions
16A)
002-466 (3.5),
16B)
002-464 (1.8)
Float Height
20mm
A
C
B
D
TMS/TMX Series (Early Style) Exploded View
