Carburetor Main Pilot Jet Throttle Valve Needle Float Mikuni Order
Jet Jet Needle Cutaway Valve Set Height No. No.
TMX35-1 4/042 #350 VM22/210 #20 6EN11-53 999-832-014-6.0 786-36004-3.5 20mm TMX35-1 001-034
TMX38-18 4/042 #370 VM22/210 #20 6EJ12-55 999-832-014-3.5 786-36004-3.5 20mm TMX38-18 001-076
TMX38-27 4/042 #370 VM22/210 #20 6EJ12-55 999-832-014-3.5 786-36004-3.5 20mm TMX38-27 001-077
Use the following part numbers when ordering for special jetting request.
Carburetor Mikuni Jetting
Reference Change
TMX35 TMX35-1 001-182
TMX38 TMX38-18 001-189
TMX38 TMX38-27 001-184
Throttle valves or TMX35 and TMX38. Sold each.
Cutaway Mikuni No. Order No.
3.0 999-832-014-3.0 002-472
3.5 999-832-014-3.5 002-473
4.0 999-832-014-4.0 002-476
5.0 999-832-014-5.0 002-474
6.0 999-832-014-6.0 002-475
Applications: TMS. Sold each.
Engine Inlet Hole Outlet Hole Mikuni No. Order No.
250cc 3.0mm 2.0mm 999-832-017 “1G” 007-410
125cc 2.0mm 1.4mm 999-832-017 “1H” 007-411
Early Style TMX
TMS Throttle Valves
TMX Series Throttle Valves (Early Style)
TMX Flat Slide Carburetors (Early Style) Standard Jetting
Special Set TMX Flat Slide Carburetors
Mikuni TMX Carburetors
The TMX series (early) carburetors feature a flat slide design in a
smooth bore venturi to provide improved throttle response and wider
power band. Later series (late) TMX feature a flat/oval type slide. Light
weight and compact body. TMX series carburetors are available
in 35mm bore size for 125cc race engines and 38mm bore sizes for
250cc race engines.
TMX Series Carburetors
Photo courtesy of 4TheRiders
