Size (mm)
A B C
D Total Width
TM36-68
42 100 176 54 78
TM40-6/HS40 44 100 165 55
––––
Carburetor Main
Main Pilot
Pilot Needle
Jet
Throttle Valve Float Mikuni Order
Jet Air Jet Jet
Air Jet Jet #568 Series Needle & Cutaway
Height No.
No.
TM36
N100.604 #130 None
VM28/486 #12.5 1.0
#P-8
9DZH6-50 TM36/137 #1.5 19mm TM36-68
001-552
TM40 (HS40)
N100.604 #165 Plugged VM28/486 #17.5 1.1
#Y-6
9DJY04-96 TM40/81
19mm TM40-6
001-085
Float Height
19mm
A
C
B
D
Mikuni TM Series Carburetors are intended for off-road riding
and racing use only. Not legal for use in California or other
locations where similar pollution laws may apply.
TM36 & TM40 (HS40) Standard Jetting Specifications
Carburetor Dimensions
TM36/TM40 (HS40) Pumper Carb Exploded View
