Mikuni’s original FLAT SLIDE Carburetor. The TM series Carburetors provide significant performance improvements over older round slide
Carburetors. Air flows faster and smoother through the TM series venturi due to the flat slide design and the jet blocks which help create smooth
bore effect. The high velocity of the air flow means a stronger vacuum at the needle jet providing more precise metering and better throttle response.
TM Flat Slide Carburetors are sold pre-jetted, jetting change and throttle valve change. (See listing below)
Please specify when ordering.
Use the following part numbers when ordering for special jetting request.
Carburetor
Jetting
Throttle Valve
Change
Change
TM24
001-170
–––––––
TM28
001-172
–––––––
TM32
001-176
–––––––
TM34
001-178
–––––––
TM36
001-180
001-181
TM38 with 47mm Spigot O.D.
001-154
001-155
TM38 with 43mm Spigot O.D.
001-152
001-153
Special Set TM Flat Slide Carburetors
Mikuni TM Flat Slide Carburetors
Carburetor
Main
Main
Pilot
Pilot Air Needle
Jet
Throttle
Mikuni
Order
Jet
Air Jet Jet
Jet
Jet
Needle
Valve & CutawayNo.
No.
TM24
4/042 #130
Fixed VM22/210 #15
–––––––
454 Series #Q-0 5N13
832-30006 #3.0 TM24-8001
001-017
TM28
4/042 #180
1.8
VM22/210 #15
–––––––
175 Series #P-8 5DP39
832-33001 #2.5 VM28-418
001-023
TM32
4/042 #250
None VM22/210 #45
–––––––
389 Series #Q-2 5FP17
832-39012 #4.0 TM32-1
001-026
TM34
4/042 #280
None VM22/210 #50
–––––––
389 Series #Q-2 5FP17
832-39012 #4.0 TM34-2
001-033
TM36
4/042 #280
None VM22/210 #50
–––––––
389 Series #Q-6 6FJ40
832-43002A #4.0 TM36-2
001-038
TM38
(*47mm)
4/042 #230
None VM22/210 #22.5
–––––––
389 Series #Q-2 6FJ41
832-43011 #4.0 TM38-85
001-060
TM38 (*43mm)
4/042 #230
None VM22/210 #22.5
–––––––
389 Series #Q-2 6FJ41
832-43011 #4.0 TM38-86
001-061
*47mm = Spigot O.D. size, *43mm = Spigot O.D. size.
TM Flat Slide Standard Jetting Specifications
TM Flat Slide with Accelerator Pump Standard Jetting Specifications
TM33
N100.64 #127.50.7
VM28/486 #37.5 1.1
640 Series #P-8 5FP96
832-38007 #1.5 TM33-8012
001-032
TM36
N100.64 #130 None VM28/486 #12.5 1.0
568 Series #P-8 9DZH6-50 TM36/137 #2.0
TM36-68
001-552
TM40 (HS40)
N100.64 #165 Plugged VM28/486 #17.5 1.1
568 Series #Y-6 9DJY04-96 TM40/81
TM40-6
001-085
TM24-8001 TM28-418
TM32-1
TM33-8012 TM34-2
TM36-2
TM36-68
TM38-85/86
TM40-6 (HS40)
Pumper
Pumper
Pumper
22 - 24mm
22 - 24mm
17 - 19mm
14mm
17 - 19mm 17 - 19mm
19mm
17 - 19mm
19mm
TM Flat Slide Float Height
The Power Jet Kit is used on 2-stroke engine applications to improve
mid-range throttle response and add additional fuel to wide open
throttle running conditions. Easily installs on TM series Carburetors.
(#80, #100 and #120 sized jets included) Sold as a kit.
Order No.
002-041
TM Power Jet Kit
TM Flat Slide Carburetors w/Accelerator Pump
Use the following part numbers when ordering for special jetting request.
Carburetor
Jetting
Throttle Valve
Change
Change
TM33
001-187
–––––––
TM36
001-185
–––––––
TM40
001-190
–––––––
TM24
TM32/TM34
TM38
TM36 Pumper
