Size (mm)
A
B
C
D
Total Width
TM33-8012
40
93
160
50
105
Float Height
14mm
A
C
B
D
Mikuni TM Series Carburetors are intended for off-road riding
and racing use only. Not legal for use in California or other
locations where similar pollution laws may apply.
Carburetor Dimensions
Carburetor Main
Main Pilot
Pilot Needle
Jet
Throttle Valve Float Mikuni Order
Jet N100.604 Air Jet Jet VM28/486 Air Jet Jet 640 Series Needle & Cutaway
Height No.
No.
TM33
#127.5
0.7 #37.5
1.1 #P-8
#5FP96 832-38007 #1.5 14mm TM33-8012
001-032
TM33 Standard Jetting Specifications
TM33-8012 Pumper Carb Exploded View
